Getting Started
Author: Brian M. Schilder
Author: Brian M. Schilder
Updated: Mar-16-2026
Source: Updated: Mar-16-2026
vignettes/echoannot.Rmd
echoannot.Rmd## Registered S3 method overwritten by 'bit64':
## method from
## print.bitstring tools
has_internet <- tryCatch(
!is.null(curl::nslookup("github.com", error = FALSE)),
error = function(e) FALSE
)Import data
To get the full dataset of all fine-mapped Parkinson’s Disease loci, you can use the following function:
merged_DT <- echodata::get_Nalls2019_merged()Annotate
Annotate SNP-wise fine-mapping results.
Here, we’re only annotating a small number of SNPs high-confidence
causal SNPs for demo purposes. The more SNPs you supply to
annotate_snps, the longer it will take to query the
selected databases for each SNP.
Note: This chunk is kept as eval=FALSE because
annotate_snps queries external databases (HaploReg,
RegulomeDB, BioMart), which can be slow and may have rate limits.
#### Only query high-confidence fine-mapping SNPs from one locus ####
dat <- merged_DT[Locus=="LRRK2" & Consensus_SNP==TRUE,]
#### Query annotations ####
dat_annot <- echoannot::annotate_snps(dat = dat,
haploreg_annotation = TRUE,
regulomeDB_annotation = TRUE,
biomart_annotation = TRUE)
knitr::kable(dat_annot)Summary plots
Credible Set bin plot
gg_cs_bin <- echoannot::CS_bin_plot(merged_DT = merged_DT,
show_plot = FALSE)Credible Set counts plot
gg_cs_counts <- echoannot::CS_counts_plot(merged_DT = merged_DT,
show_plot = FALSE)## Warning in ggplot2::geom_bar(stat = "identity", color = "white", size = 0.05): Ignoring unknown parameters: `size`
## Ignoring unknown parameters: `size`Epigenomic data
gg_epi <- echoannot::peak_overlap_plot(
merged_DT = merged_DT,
include.NOTT2019_enhancers_promoters = TRUE,
include.NOTT2019_PLACseq = TRUE,
#### Omit many annotations to save time ####
include.NOTT2019_peaks = FALSE,
include.CORCES2020_scATACpeaks = FALSE,
include.CORCES2020_Cicero_coaccess = FALSE,
include.CORCES2020_bulkATACpeaks = FALSE,
include.CORCES2020_HiChIP_FitHiChIP_coaccess = FALSE,
include.CORCES2020_gene_annotations = FALSE)## ++ NOTT2019:: Getting regulatory regions data.## Importing Astrocyte enhancers ...## Importing Astrocyte promoters ...## Importing Neuronal enhancers ...## Importing Neuronal promoters ...## Importing Oligo enhancers ...## Importing Oligo promoters ...## Importing Microglia enhancers ...## Importing Microglia promoters ...## Converting dat to GRanges object.
## Converting dat to GRanges object.## 48 query SNP(s) detected with reference overlap.## ++ NOTT2019:: Getting interaction anchors data.## Importing Microglia interactome ...## Importing Neuronal interactome ...## Importing Oligo interactome ...## Converting dat to GRanges object.## 52 query SNP(s) detected with reference overlap.## Converting dat to GRanges object.## 44 query SNP(s) detected with reference overlap.## Warning: Using `size` aesthetic for lines was deprecated in ggplot2 3.4.0.
## ℹ Please use `linewidth` instead.
## ℹ The deprecated feature was likely used in the echoannot package.
## Please report the issue at <https://github.com/RajLabMSSM/echoannot/issues>.
## This warning is displayed once per session.
## Call `lifecycle::last_lifecycle_warnings()` to see where this warning was
## generated.## Warning: The `size` argument of `element_line()` is deprecated as of ggplot2 3.4.0.
## ℹ Please use the `linewidth` argument instead.
## ℹ The deprecated feature was likely used in the echoannot package.
## Please report the issue at <https://github.com/RajLabMSSM/echoannot/issues>.
## This warning is displayed once per session.
## Call `lifecycle::last_lifecycle_warnings()` to see where this warning was
## generated.## Warning: `aes_string()` was deprecated in ggplot2 3.0.0.
## ℹ Please use tidy evaluation idioms with `aes()`.
## ℹ See also `vignette("ggplot2-in-packages")` for more information.
## ℹ The deprecated feature was likely used in the echoannot package.
## Please report the issue at <https://github.com/RajLabMSSM/echoannot/issues>.
## This warning is displayed once per session.
## Call `lifecycle::last_lifecycle_warnings()` to see where this warning was
## generated.
Super summary plot
Creates one big merged plot using the subfunctions above.
super_plot <- echoannot::super_summary_plot(merged_DT = merged_DT,
plot_missense = FALSE)## Warning in ggplot2::geom_bar(stat = "identity", color = "white", size = 0.05): Ignoring unknown parameters: `size`
## Ignoring unknown parameters: `size`## Importing previously downloaded files: /github/home/.cache/R/echoannot/NOTT2019_epigenomic_peaks.rds## ++ NOTT2019:: 634,540 ranges retrieved.## Converting dat to GRanges object.## 113 query SNP(s) detected with reference overlap.## ++ NOTT2019:: Getting regulatory regions data.## Importing Astrocyte enhancers ...## Importing Astrocyte promoters ...## Importing Neuronal enhancers ...## Importing Neuronal promoters ...## Importing Oligo enhancers ...## Importing Oligo promoters ...## Importing Microglia enhancers ...## Importing Microglia promoters ...## Converting dat to GRanges object.
## Converting dat to GRanges object.## 48 query SNP(s) detected with reference overlap.## ++ NOTT2019:: Getting interaction anchors data.## Importing Microglia interactome ...## Importing Neuronal interactome ...## Importing Oligo interactome ...## Converting dat to GRanges object.## 52 query SNP(s) detected with reference overlap.## Converting dat to GRanges object.## 44 query SNP(s) detected with reference overlap.## CORCES2020:: Extracting overlapping cell-type-specific scATAC-seq peaks## Converting dat to GRanges object.## 13 query SNP(s) detected with reference overlap.## CORCES2020:: Annotating peaks by cell-type-specific target genes## CORCES2020:: Extracting overlapping bulkATAC-seq peaks from brain tissue## Converting dat to GRanges object.## 4 query SNP(s) detected with reference overlap.## CORCES2020:: Annotating peaks by bulk brain target genes## Converting dat to GRanges object.## 70 query SNP(s) detected with reference overlap.## Converting dat to GRanges object.## 72 query SNP(s) detected with reference overlap.## + CORCES2020:: Found 142 hits with HiChIP_FitHiChIP coaccessibility loop anchors.## Warning: The dot-dot notation (`..count..`) was deprecated in ggplot2 3.4.0.
## ℹ Please use `after_stat(count)` instead.
## ℹ The deprecated feature was likely used in the echoannot package.
## Please report the issue at <https://github.com/RajLabMSSM/echoannot/issues>.
## This warning is displayed once per session.
## Call `lifecycle::last_lifecycle_warnings()` to see where this warning was
## generated.## Warning: Removed 83 rows containing missing values or values outside the scale range
## (`geom_bar()`).
